Axim FC-1000 Series Universal Surface Mounted Door Closer Complete with Parallel Bracket.
The Axim FC-1000 series of overhead surface mounted door closers is perfect for applications where a concealed closer is not suitable, such as bridging thermal breaks or retro-fit, the FC-1000 range of surface mounted closers provides a solution.
- Slim line design suitable for doors that open out against adjacent walls.
- Fire tested to BS 476-22 1987.
- 2 closing strengths available for widths up to 800mm
- Die cast aluminium body.
- Suitable for single action doors, either right or left hand opening 90 and 180 degrees.
- Reversible for standard top jamb and parallel arm installations.
- Fixings provided for both timber and metal doors.
- Anodised dress plates conceal fixings after installation.
- Easy to follow instruction guide and full size template packed with every unit.
- Silver finish.
Adjustment.
Two valve screws provide full hydraulic control from 180 degrees - 15 degrees of closing and 15 degrees - 0 degrees latching.
Accessories.
- Hold open arm (plunger type) adjustable for any degree of retention.
- Flat top bracket for installation on door frame when direct fixing is not possible.
- FC-1020-P-AL = Size No. 2
- FC-1030-P-AL = Size No. 3
